Properties
●The spindle rotates about 180 degrees (depending on the thickness of the terminals).
●Quick-change applicator base plate.
●All parameters are adjusted with touch screen fine adjustment, which is simple and convenient.
●The touch screen adjusts the fine adjustment of crimping height, and the adjustment pre-cision is +/-0.01mm.
●The upper limit of the thickness test of crimping terminal is 0.03mm, and the lower limit is - 0.03mm (can check whether the applicator has terminals and re-crimping).
●Welded steel, machined base and frame.
●The speed of crimping can be adjusted, and the speed of two segments can be set and the both speeds can be adjusted.
●The holding time can be set when crimping in the lowest point.
●The setting of the crimping height can detect the alarm immediately: no terminal,re-crimping,
●no wire, the wire without stripper, and cut off the inner of wire when crimping
●Servo frequency converter. Machine cycle guarantees an optimal force action.
●The stroke height of the upper and lower crimping blades can be measured automatically.

CH-2T-S/CH-2.5T-S/CH-3T-S Servo Crimping Machine adopts servo motor drive system, and the crimping height can be set by automatic detection and alarm system. The repeatability precision of the crimping force is very stable, the all parameters input by the touch screen which is convenient and simple. Suitable for most industrial terminal crimping standards, and miniaturized crimping applicator on the left, back feeding terminals; Suitable for high - demand terminal crimping, cost - performance is the best also.
